1/2 X 1/2-20 Economy Panhard Bar Kit with Bung .065, Rod End, Heim Joint LH + RH

Product categories
Product tags
axle bearing belt bolt bracket brake cable brake disc brake disk brake pads centrifugal clutch clutch clutch cable cylinder kit dipstick disc-brake disc brakes disk brake drive belt exhaust muffler pipe exhaust muffler tube exhaust pipe front fork gasket handlebar holder lamp lantern latch LED Lift Kit light lowering kit muffler protective cover rim seat shaft shock absorber sprocket stock switch throttle cable tool washer wheel hub
1/2 X 1/2-20 Economy Panhard Bar Kit with Bung .065, Rod End, Heim Joint LH + RH
1/2 X 1/2-20 Economy Panhard Bar Kit with Bung .065, Rod End, Heim Joint LH + RH - Image 2
1/2 X 1/2-20 Economy Panhard Bar Kit with Bung .065, Rod End, Heim Joint LH + RH - Image 3
1/2 X 1/2-20 Economy Panhard Bar Kit with Bung .065, Rod End, Heim Joint LH + RH - Image 4

1/2 X 1/2-20 Economy Panhard Bar Kit with Bung .065, Rod End, Heim Joint LH + RH

SKU QT.05208 '843718105038 Category Tags ,

1/2 X 1/2-20 Economy Panhard Bar Kit with Bung .065, Rod End, Heim Joint LH + RH

1 Right Hand & 1 Left Hand
Rod End Body Material: C1045 Steel Heat Treated, Silver Zinc Plated
Rod End Ball Material: 52100 Bearing Steel Precision Ground Heat Treated, Hard Chrome Plated
Jam Nut Specs: Thread: 1/2-20, Width: 0.302-0.323, Height: 0.736-0.750
Bar Kit Specifications
Rod End
Thread Size: 1/2″-20
Ball Bore: 0.500″
Ball Width: 0.625″
Centerline Length: 2.438″
Thread Length: 1.500″
Load Capacity: 12,224 lbs
Bung
Material: 1045 Steel
Thread Size: 1/2″-20
Fits Tube Size: 1″ OD. x .065″ Wall x 0.85″ ID
Jam Nut
Thread Size: 1/2″-20
Width: 3/4″
Height: 5/16″
